Description

• Medical Grade – heavy duty construction
• 16 Gauge Type 304 Stainless Steel
• #4 Finish
• Integral Emergency Eyewash
• Two Adjustable Thermostatic Mixing Valve
• Automatic Timer, Knee-operated or Electronic Infra- Red sensor
• Removable Bay Panels
• 115°F Temperature Protection
• Anti-Splash Tub
• Removable Shower Head
• 1 station sink sizes
• Extra small scrub sink models available in 28 inches
• Pedestal Base or Wall Mounting with Chair Carrier
• Flow rates are optional between 1.5 to 2.5 gpm
• Adjustable Pressure Regulator

  Handwashing Scrub Sink Requirements

  • A sink must be available for hand-washing
  • A plumbed Eyewash station meeting applicable laws andregulations must be available.
  • Locations of water sources and drains will not interfere with required ISO classifications
  • No sinks or floor drains are included in the HD buffer.
  • In ISO Class 7 ante-room, a hand washing sink must be placedin the ante-room at least 1-meter from the entrance to the HD buffer room to avoid contamination migration into the negative pressure HD buffer room
  • A hand-washing sink must be placed at least 1 meter from C-PEC and may be either inside the non classified room or directly outside the C-SCA.

    Eyewash Requirements

  • It is required that the Eyewash installed on USP 800 Handwashing Scrub Sink has a separate mixing valve to meet ANSI z358.1-2014 requirements and prevent users from burning their eyes.
    • Factory Pre piped for easy installation
    • 2 polypropylene spray heads
    • each spray head has a flip-top dust cover
    • Internal 1.6 GPM flow control and filter to remove impurities from water
    • Meets ANSI z358.1-2014
    • dual thermostatic mixing valves ensuring temperature control protection
    • easy 65-100 degree swing down to activate water flow
    • In-line strainer to protect spray heads and valve components from debris in waterline
